UNI-T UTG9005C-II Arbitrary Waveform Function Generator in Pakistan

Regular price Rs 0
Regular price Rs 0 Sale price Rs 0
Sale Sold out
BR2389-W


This is UNI-T UTG9005C-II function / arbitrary waveform generator; 5MHz single-channel digital signal source with 125MS / s sampling rate. This is a very basic tool for an electronics lab.    The UTG9000C-II Series Function/Arbitrary Waveform Generator uses the direct digital synthesis technology, which can generate the accurate, stable,    pure, and low-distortion waveform output, and the resolution is as low as 1? Hz. It is an economical, high-performance, and multifunctional function/arbitrary waveform generator. With the convenient operation interface, excellent technical indicators, and humanized graphic display, this multi-purpose equipment can meet your learning and testing requirements and improve work efficiency.

Applications:

 Designing, testing, troubleshooting, and repairing electronic and electroacoustic devices, such as circuit and equipment testing in cellular and wireless systems, broadcasting, television, and radio systems; semiconductor component testing, etc.

Features:

  • 1Output waveforms: Sine, square, ramp, pulse, noise, DC, arbitrary
  • Output frequency range: Sine/square, 5MHz
  • High-accuracy, broad-band 6-bit frequency counter, range: 100mHz~100MHz
  • 4W power output
  • EBIT LCD screen
  • Package Include:
  • 1xUNI-T UTG9005C-II

Documentation:

  1. UTG9000C-II Software
  2. UTG9000C-II English manual
  3. Specifications
  4. Model UTG9005C-II
  5. Channel 1
  6. Bandwidth 5MHz
  7. Sampling rate 125MS/s
  8. Vertical resolution 14 bits
  9. Waveforms Sine, square, pulse, ramp, noise, DC, arbitrary (20 sets inside )
  10. Sweep modes Logarithmic, linear

Frequency Characteristics:

  • Sine 1?Hz~2MHz
  • Square 1?Hz~2MHz
  • Ramp 1?Hz~200kHz
  • Pulse 1?Hz~2MHz
  • Arbitrary 1?Hz~1MHz
  • Resolution 1? Hz
  • Accuracy Within 90 days ± 50ppm
  • Within 1 year ± 100ppm
  • 18?~28?

Output Characteristics:

  1. Impedance 50?/High Z
  2. Amplitude range 1mVpp~10Vpp (50?); 2mVpp~20Vpp (high Z)
  3. DC offset range -5Vpp~5Vpp (50?) (AC+DC); -10Vpp~10Vpp (high Z) (AC+DC)
  4. Amplitude resolution 1mV
  5. General Characteristics
  6. Power 100~240VAC, 50Hz/60Hz
  7. Display EBTN LCD
  8. Product color White and grey
  9. Product net weight 2.8kg

Package Includes:

1 x UNI-T UTG9005C-II Arbitrary Waveform Function Generator

Industryparts.pk is the Best Online Shopping website for UNI-T UTG9005C-II Arbitrary Waveform Function Generator. Here you get UNI-T UTG9005C-II Arbitrary Waveform Function Generator at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
