Surge Protective Devices (SPD) are used to protect the electrical installation, which consists of the consumer unit, wiring, and accessories, from electrical power surges known as transient overvoltages.

 Specification:

• Main technical parameters TEN4-C100
• Max continuous operating voltage Uc(VAC) 440v
• Voltage protection level Up(kV)≤ 2.8kv
• Max discharge current (8/20μS) max(kA) 100kA(8/20μS)
• Nominal discharge current (8/20μS) ln(kA) 40
• Response time ns <25
• Degree of protection IP20
• Operating state/ fault indication Green/ Red
• Remote signal function Can also picking
• Remarks Other Uc can be customized
• (420VAC,320VAC,275VAC etc.)
• SPD according to IEC61643-1/EN61643-1 type2

Industryparts.pk is the Best Online Shopping website for Surge protection device 4P SPD/surge arrester /surge protector KDY-100 100KVA. Here you get Surge protection device 4P SPD/surge arrester /surge protector KDY-100 100KVA at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.

Package Includes:

1 x Surge protection device
