The SK-WY Non-invasive Ultrasonic Level Gauge No tank break-in ultrasonic level transmitter is a device that uses ultrasonic waves to measure the level of liquids in tanks and other containers without having to break into the tank. It is a non-contact sensor that emits a pulse of ultrasonic sound and then measures the time it takes for the sound to return after it reflects off the surface of the liquid. The distance to the liquid surface is calculated based on the time of flight of the sound pulse.

Features of SK-WY Non-invasive Ultrasonic Level Gauge:

• Non-invasive measurement
• High precision (±1mm)
• Wide measurement range (0 to 10m)
• Suitable for a variety of liquids
• Easy to install and use

Specification of SK-WY Non-invasive Ultrasonic Level Gauge:

• Measurement principle: Ultrasonic
• Measurement range: 0 to 10m
• Accuracy: ±1mm
• Output signal: 4-20mA, RS-485
• Power supply: 24V DC
• Operating temperature: -20°C to +80°C
• Temperature: (-40~80)°C
• Accuracy: 0.1%
• Signal output:(4-20)mA 24V DC Two Wire +HART
• Protection rating: IP 67
• Enclosure: Aluminum housing

Dimensions:

• Diameter: 76mm
• Length: 225mm

Uses:

• Measuring the level of liquids in tanks, reservoirs, and other vessels
• Monitoring inventory levels
• Controlling pumps and valves
• Preventing overfill and underfill conditions

Industryparts.pk is the Online Shopping website for SK-WY Non-invasive Ultrasonic Level Gauge. Here you get SK-WY Non-invasive Ultrasonic Level Gauge at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.

Package includes:

• SK-WY Non-invasive Ultrasonic Level Gauge
• User manual
