UT610 series  LCR Meters are more advanced meters used to measure inductance, capacitance, and resistance. Advanced features include series/parallel measurement modes, quality factor/loss/phase angle measurements, equivalent/DC resistance measurements, and 5 kinds of measurement frequency in AC mode for selection.  UT610 series can be easily operated in production lines, component inspection, and electronic maintenance. This  Handheld RLC meter a good choice if you need to record readings for future reference. Capacitance Inductance Meter Ut612 has a quick-touch data hold function that stabilizes fluctuating readings on the screen for a few seconds, giving you the chance to write down measurements when appropriate. What’s more, the LCR Tester can be used with circuits in both series and parallel. This makes it compatible with a wide range of electric systems.

Features:

• Auto LCR smart check and measurement
• Real-time display test frequency
• Measurement mode: series/parallel
• Auto power off
• Low battery indication
• Data Hold
• Relative mode
• USB interface
• USB interface / PC data records 60000
• LCD backlight
• Analogue Bar Graph 26
• Deviation ratio measurement
• Screening function
• Calibration function
• Output impedance 120Ohm

Specifications :

1. Model: UT603
2. Power:9V Batteries(6F22)
3. Product Color: Red and Grey
4. Display: 61mm x 32 mm
5. Item size: 172mm x 83mm x 38mm
6. Display Count: 19999
7. D/Q display count: 1999
8. Operating Voltage: 0.6Vrms
9. Frequency: 100Hz/120Hz/1kHz/10kHz/100kHz
10. Resistance (R):
    • Range: 20Ω~200MΩ
    • Accuracy:  ±(0.3%+5)
11. Capacitance(C):
    • Range: 200pF~20mF
    • Accuracy: ±(0.5%+5)
12. Inductance(L):
    • Range: 20uH~2000H
    • Accuracy:  ±(0.5%+5)

Package Include:

• 1x Digital RC Meter UNI T UT612
