Danfoss KP pressure switches are used for regulating, monitoring and alarm systems in industrial applications. The KP series are suitable for gaseous media and air. They are fitted with a single-pole switch changeover (SPDT) and can control single-phase ac motors of up to 2 kW directly.
Features:
- Enclosure IP44 when mounted with top cover and backplate
- Also available with enclosure IP55 for OEM customers
- Small dimensions – space saving – easy to install
- Shock and impact resistant
- Also available with gold plated contact systems
Specifications:
- Manufacturer: Danfoss
- Model No: KP35
- Measuring Parameters: Pressure -0.2 to 7.5 Bar
- Differential Pressure: 0.7 to 4 bar
- Reset type: Automatic
- Operating Pressure: 0.2 to 7.5 bar
- Burst Pressure Min.: 1050 bar
- Ambient Temperature: -40°C to 65°C
- Media Temperature:-40°C to 100°C
-
IP Rating: IP 30
- Standards: ISO 228-1
- Enclosure: NEMA 1
- Dimension:2.5 X 5 X 9 cm
- Weight:500 Grams
Uses
- Protecting compressors in refrigeration systems
- Pressure control in air-conditioning units
- Industrial pressure monitoring and control
- Safety switch in HVAC systems
- Triggering alarms or shutdowns when pressure is abnormal
Package Include:
1 x Danfoss Pressure Switch KP35 China
