The Omron E6B2-CWZ6C is a precise incremental rotary encoder designed to convert shaft rotation into accurate digital signals. With a resolution of 300 pulses per revolution (PPR), it provides reliable position and speed feedback for motors and automation systems. Compact and durable, it fits easily into industrial machinery and control panels. This encoder improves efficiency, accuracy, and safety in motion control applications. Ideal for industrial, robotics, and automated equipment setups.
Features:
- High-resolution 300 pulses per revolution (PPR).
- Provides precise position and speed feedback.
- Compact and easy to install in machinery.
- Durable design for industrial environments.
- Compatible with various control and drive systems.
Specification:
- Series: E6B
- Encoding Method: Incremental
- Resolution P/R: 300
- Control Output (Output type): NPN open collector output
- Max Force Radial: 30 N
- Max Force Thrust: 20 N
- IP Rating: IP50
- Power Supply Voltage: 5 VDC -5% to 24 VDC +15% (ripple (p-p): 5% Max.)
- Max Rotation Frequency r/min: 6000 r/min
- Height (mm): 40
Uses:
- Position and speed measurement in motors.
- Motion control in industrial automation systems.
- Robotics and conveyor system feedback.
- Precision monitoring for machinery and CNC equipment.
- Enhancing accuracy and efficiency in automated processes.
Package includes:
1 x 300PPR OMRON Incremental Rotary Encoder E6B2-CWZ6C
Industryparts.pk is the Online Shopping website for 300PPR OMRON Incremental Rotary Encoder E6B2-CWZ6C in Pakistan. We deliver in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
