Description:



1. 2m drop proof, IP54, ETL/Intertek certified 3rdedition CE



2. Coil diameter: 0.75cm, bending length: 24.5cm for UT281A and 45.7cm for UT281C



3. Large LCD display for clear reading



4. True RMS



5. Long press INRUSH key for 2s to measure inrush current



6. Datahold, backlight, auto power off



Specification:



Basic Functions	Range	Basic Accuracy
Model		UT281C
Max current  measurement (AC)	0.00A ~ 3000A	±(3%+5)
Current measurement  (AC)	0.00A ~ 30.00A	±(3%+5)
Current measurement  (AC)	0.0A ~ 300.0A	±(3%+5)
Current measurement  (AC)	0A ~ 3000A	±(3%+5)
Inrush current  measurement	0.00A ~ 3000A	For reference
Frequency response	45Hz~500Hz (sine wave)	?
Jaw size	Rogowski flex coil (diameter:  8mm)	Bending length: 18 inches  (45.7cm); radius: around 3.1 inches (8cm)
True RMS measurement		?
Measuring digit  conversion rate	times/s	3
LCD display (TN)	interface	Single display
Manual range	?
Auto power off	?
Buzzer	?
Low battery  indication	?
Data hold	?
Manual backlight	?
Working temperature	0°C ~ 50°C
2m drop proof	?
Protection grade	IP54
Safety certification  grade	CAT IV 600V
General features
Device color	Red and grey
Device weight		236g
Device size		350mm × 190mm × 55mm
Standard individual  packing	Gift box, blister, English  manual
