3/29 or more correctly 3/0.029” is a classic imperial British Standard 2004 compliant electric cable used for low voltage applications in houses, offices, and commercial buildings. You may not want to compromise on the quality of this cable as a low-quality cable not only degrades the quality of all your equipment, devices, and appliances but also doubles your electricity bill due to more heat generation and electricity loss. This heat generation can also damage the cable.

3/0.029” cable from Unicore Cables is manufactured with standard high quality and occasionally tested by PCSIR and UET laboratories in addition to the routine in-house tests. Our production staff is careful and highly experienced and sufficiently capable to ensure the application of quality procedures during the manufacturing of the cable.

The use of a 99% pure high quality properly drawn and annealed copper conductor in electric cables by Unicore Cables ensures very low electric resistance and makes sure that the current flows in the wires without creating much heat. Twisted strands in our manufactured cables offer the best electrical characteristics and reduce the chances of a short circuit to very low.

Specifications:

• Brand Name Unicore Cables
• Cable Identification Stamp 3/0.029" S/C CU/PVC 250/440 V ELECTRIC CABLE
• Cable Type General Wiring
• Cores Single Core
• Weight 2.03 KG
• Colors Red, Black, Blue, Yellow, Green, White
• Length 90 meters
• Twisted Copper Yes
• Cable Life 20 years or more in typical wiring conditions
• Application House, Office, Building, Commercial
• Cable Shape Round
• Make Pakistan

Technical Data:

• No. of Strands 3 strands of 99% pure copper are twisted to form a rope for better electrical results and to reduce the chances of electrical short circuits.
• Strand Diameter 0.029 Inch or 0.7366 mm
• Conductor Class Class-2 Stranded
• Conductor Type Copper
• Conductor Purity 99%
• Insulation Type PVC (Poly Vinyl Chloride)
• Insulation Thickness 0.89 mm
• Cable Diameter 3.39 mm
• Standard BSS-2004
• Temperature Rating -20C˚ to 70C˚
• Dc Resistance 14.03 OHM/KM at 20° C
• Voltage Rating 250/440V
• Ampere Rating 11 Amps (may vary in different circumstances)

Package Includes:

1 x Unicore Cables 3/29 Electric Cable 90 Meter Coil
