UNI-T UT8805E Benchtop Digital Multimeter in Pakistan

SKU:BR3278

Regular price Rs 0
Regular price Rs 0 Sale price Rs 0
Sale Sold out

UNI-T UT8805E is a digital desktop multimeter with a True RMS function. It is used to measure DC and AC current, DC and AC voltage, resistance, capacitance, frequency, and temperature, as well as to check the conductivity of electrical circuits and test diodes and transistors.

Features:

  • True RMS function.
  • 4.3-inch TFT-LCD backlit display, counts: 200,000.
  • Automatic range selection.
  • High measurement speed: up to 5000 measurements per second.
  • HOLD function.
  • MIN / MAX function.
  • Graphic analog indicator.
  • Checking the conductivity of electrical circuits.
  • Testing of diodes and triodes.
  • Relative measurements.
  • Automatic shutdown.
  • Low battery indicator.

Specifications:

  • Constant voltage 20 mV / 2 V / 20 V / 200 V / 1000 V ± (0.008% + 0.003%)
  • Alternating voltage 200 mV / 2 V / 20 V / 200 V / 750 V ± (0.19% + 0.05%)
  • Direct current 200 μA / 2 mA / 20 mA / 200 mA / 2 A / 10 A ± (0.050% + 0.005%)
  • Alternating current 2 mA / 20 mA / 200 mA / 2 A / 10 A ± (0.30% + 0.1%)
  • Resistance 200 Ohm / 2 kО / 20 kО / 200 kО / 2 Mм / 10 Mм / 100 Mм ± (0.012% + 0.003%)
  • Capacity 2 nF / 20 nF / 200 nF / 2 μF / 20 μF / 200 μF / 2 mF ± (1% + 0.5%)
  • Frequency 20 Hz ~ 1 MHz ± (0.01% + 0.003%)
  • Temperature -270 ° C ~ 1760 ° C ± 0.5 ° C
  • General characteristics
  • Display 4.3 "TFT LCD: 200,000 readings
  • Sampling speed 5000 rpm
  • Internal memory 1 GB (storage of up to 10,000 results)
  • Frequency response 100 kHz
  • Input resistance ≥10 MО
  • Interfaces USB Host, USB Device, LAN, RS-232
  • Nutrition AC 100 V ~ 120 V: 45 Hz ~ 440 Hz; AC 200 V ~ 240 V: 45 Hz ~ 66 Hz
  • Dimensions 239 mm × 100 mm × 344 mm
  • Weight 4.4 kg

Package Includes:

 1 x UNI-T UT8805E Benchtop Digital Multimeter

Industryparts.pk is the Best Online Shopping website for UNI-T UT8805E Benchtop Digital Multimeter. Here you get UNI-T UT8805E Benchtop Digital Multimeter at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
