UNI T DC Power Supply UTP3305C is a high-performance programmable linear DC power supply with single channel output and process control. This UTP-3305C power supply can meet diversified measurement needs with pure signal output, competitive specifications, and a variety of interfaces. This linear power supply is built with voltage and current overload protection, a convenient operation panel, and one key storage recall. This best power supply can be used in the aging test, electronics circuit behavior test, and automated system test of different environments. This signal channel power supply is used for electronics design, battery charging, electrical vehicle, research labs, and education sectors.

Features:

• High precision 4-bit voltage and current display
• Overvoltage and current protection
• Over-temperature protection
• One-click data recall (up to 5 groups); Optional LAN interface
• Power-off memory; Software calibration; Keyboard lock

Specifications:

• Output voltage: 0~30V (CH1/CH2)
• Output current: 0~5A (CH1/CH2)
• Output power: 315W
• Load regulation voltage: <0.01%+5mV
• Load regulation Current: <0.1%+10mA
• Line regulation voltage: <0.01%+3mV
• Line regulation current: <0.1%+3mA
• Resolution voltage: 10mV
• Resolution current: 1mA
• Accuracy (25℃±5℃) voltage: <0.5%+20mV
• Accuracy (25℃±5℃) current: <0.5%+10mA
• Ripple (20Hz~20MHz) voltage: ≤2mVrms
• Ripple (20Hz~20MHz) current: ≤3mArms
• Output temperature coefficient voltage: ≤150ppm
• Output temperature coefficient current: ≤150ppm
• Voltage rise delay: ≤100ms (10% rated load)
• Parallel/Series load regulation: ≤0.1%+0.1V
• Output temperature coefficient voltage:
• CH3 output features voltage: 5V
• CH3 output features current: 3A
• CH3 output features voltage accuracy: ±50mV
• CH3 output features load regulation: ±50mV
• Interfaces: USB Device, RS-232
• Power: AC 100V/120V/220V/230V±10%, 50Hz/60Hz
• Display: 4 windows, LED

Package Include:

          1 x UNI T Programmable DC Power Supply UTP3305C
