UNI T Adjustable Variable Power Supply 60V 10A UTP3305-II in Pakistan

SKU:BR7089-d5

Regular price Rs 60,950
Regular price Rs 61,500 Sale price Rs 60,950
Sale Sold out

UNI-T UTP3305 or UTP-3305 is one of the best variable DC power supplies which have features of low ripple/noise, constant voltage/current, overload protection, parallel/series, and output on/off control. This bench power supply has a Dual-channel, two circuits of adjustable output voltage 0~32V, and one circuit of fixed voltage 5V. This best lab power supply is Low ripple/noise, overload protection, and Output on/off control. One of the best DC voltage power supply units, especially for university labs, mobile repairing, notebook/ laptop troubleshooting. This UTP 3305 lab power supply kit is more useful and easy to use than the HR1203 power supply.

Features:

  • Dual-channel, two circuits of adjustable output voltage 0~32V and one circuit of fixed voltage 5V.
  • Master-slave tracking, constant voltage and current, I circuit can be used for master-slave tracking and used in parallel or in series.
  • Forced ventilation, temperature control-cooling system. When the temperature reaches 65, the device dissipates heat automatically.
  • Display mode: LED digital tube display, can show voltage and current simultaneously.
  • Low ripple, low noise.
  • High regulation: 0.01%.
  • Output ON/OFF control.
  • Constant voltage and constant current operation.
  • Optional European standard output terminal.
  • Overload protection, reverse polarity protection.

Specifications :

  • Model : UTP3305
  • Output voltage: CH1, CH2 0~32V
  • CH3: 5V
  • Output current: CH1, CH2 0~5A
  • CH3:3A
  • output power:335W
  • Load regulation :CV≤1×10-4 +3mV, CC≤2×10-4 +3mA
  • Ripple and noise: CV≤1mVrms; CC≤3mArms
  • Output regulation resolution CV: 100mV (typical), CC: 10mA (typical)
  • Tracking bias: 5×10-3 +10mV
  • Reliability MTBF(e): ≥2000hrs
  • Display mode 3-bit voltage and current dual display
  • Features Auto conversion of constant voltage and current with current limit protection;
  • CH1 and CH2 master-slave tracking in series
  • General Characteristics
  • Power Input voltage: 115V AC/230V AC; Frequency: 47Hz~63Hz
  • Product color White and grey
  • Product net weight 10kg
  • Product size 260mm x 170mm x 315mm
  • Standard accessories Power cord, output cables
  • Standard individual packing Carton box, English manual

Industryparts.pk is the Best Online Shopping website for UNI T Adjustable Variable Power Supply 60V 10A UTP3305-II in Pakistan. We deliver in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.

Package Includes:

         1 x UNI T Adjustable Variable Power Supply 60V 10A UTP3305-II

UNI T Adjustable Variable Power Supply 60V 10A UTP3305-II in Pakistan
