Voltage control relays are designed to protect devices with sensitive operating voltage from damage caused by mains voltage. Over-Voltage : 400V - 510V AC (Adjustable) (Can Be Disabled) Under Voltage: 260V - 370V AC (Adjustable) (Can Be Disabled) Error Waiting Time : 0,1sec.

https://youtu.be/4g7V_qwMFwA

1. Over Voltage Protection: The relay is designed to detect and protect against overvoltage conditions in electrical systems. It monitors the voltage level and activates the appropriate response when the voltage exceeds the set threshold.

2. Under Voltage Protection: The GKT-03F also provides protection against undervoltage conditions. It monitors the voltage level and triggers the appropriate action when the voltage drops below the specified threshold.

3. Adjustable Voltage Thresholds: The relay allows for adjustable voltage threshold settings, which can be customized according to the specific requirements of the system. This flexibility enables precise voltage monitoring and protection.

4. Delay Function: The GKT-03F may offer a delay function, allowing a user-defined delay before activating the protection response. This feature helps prevent false alarms and allows for time-dependent voltage monitoring.

5. LED Indicators: The relay typically includes LED indicators that provide visual feedback on the status of the voltage levels, making it easy to identify overvoltage or undervoltage conditions.

6. Fault Diagnosis: Some models may feature fault diagnosis capabilities, which provide information about the nature of the fault or abnormal voltage condition. This feature aids in troubleshooting and maintenance.

7. Reset Function: The GKT-03F may have a manual or automatic reset function that allows for the relay to be reset once the voltage levels return to normal, resuming normal operation.

8. Compact Design: The monitoring relay is designed to have a compact form factor, allowing for easy installation and integration into control panels or electrical enclosures.

9. Wide Voltage Range: It is typically compatible with a wide voltage range, making it suitable for various applications and electrical systems.

10. Reliable Performance: The GKT-03F Monitoring Relay is designed to provide reliable and accurate voltage monitoring and protection, ensuring the safe operation of electrical systems.

Specifications:

• Brand name: TENSE
• Certification: THIS
• Origin: CN (Origin)
• Theory: voltage relay
• Custom: Yes
• Touch load: Weak power
• Voltage: 380V
• Model Number: GKT-03F
• Protective Feature: SEALED
• Power source: AC
• Usage: Protective
• Protection Item 1: Over Volt
• Protection Item 2: Under Volt
• Protection Item 3: Phase Failure
• Protection Item 4: Phase Sequence

Industryparts.pk is the Best Online Shopping website for TENSE GKT-03F Over Voltage and Under Voltage Monitoring Relay. Here you get TENSE GKT-03F Over Voltage and Under Voltage Monitoring Relay at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.

Package includes:

       1 x TENSE GKT-03F Over Voltage and Under Voltage Monitoring Relay
