A float switch works to detect the level of liquid in a tank by using a float, magnet, and reed switch system that automatically opens and closes when water levels rise and fall inside the tank. According to WikiPedia, “A float switch is a type of level sensor, a device used to detect the level of liquid within a tank…

Features:

1. Used to sense the level of liquid within a tank.
2. Lightweight and simple working principle, high reliability.
3. The switch may activate a pump, an indicator, an alarm, or other devices.
4. This float switch is a simple structure, easy installation liquid level controller.
5. Widely used in electronic, electrical, chemical, water treatment, drainage, and other fields. The versatility of this vertically mounted sensor means that it can be installed either at the top or base of your tank, depending on whether you wish to detect the water's rise or fall.

Specifications:

• Material: Stainless Steel
• Max. Contact Rating: 10W / 50W
• Max. Switching Voltage: 240V AC
• Max. Breakdown Voltage: 220V DC
• Max. Switching Current: 0.5A
• Operating Pressure: 10kg/cm
• Max. Pressure: 0.2 Mpa
• Applicable Proportion: 0.75
• Operating Temperature: -10 ~ +120
• Installation Method: Vertical Mounting
• Thread Diameter: As request
• 6 Size Optional:
• 100mm / 3.94 inch
• 150mm / 5.91 inch
• 200mm / 7.87 inch
• 250mm / 9.84 inch
• 300mm / 11.81 inch
• 400mm / 15.75 inch

Package Includes:

1 x Stainless Steel Float Switch Tank Liquid Water Level Sensor
