The SMC ISE30‑01‑28 Digital Pressure Switch is a compact and precise instrument designed for industrial and automation use. It measures pressure up to 1.000 MPa with excellent resolution and accuracy, and features a two-color digital display that clearly indicates whether pressure is within the desired range. With programmable setpoints, adjustable hysteresis, and optional analog outputs (1–5 V or 4–20 mA) alongside NPN or PNP switch outputs, it offers flexible control options. This switch is perfect for pneumatic systems, temperature regulation, packaging equipment, hydraulic controls, and robotic automation. Its user-friendly interface and panel-mountable design make setup and monitoring fast and simple.
Features:
- Digital display with dual-color (red/green) LED for clear status indication
- Compact and lightweight design for easy panel mounting
- Two independent switch outputs (NPN/PNP type selectable)
- Analog output available (1–5 V or 4–20 mA)
- User-friendly 3-button operation
- Adjustable setpoints, hysteresis, and response time
- Overpressure and reverse polarity protection
- RoHS compliant
Specification:
- Model: ISE30-01-28
- Rated Pressure Range: 0 to 1.000 MPa
- Supply Voltage: 12–24VDC (Class 2)
- Output: 2 switch outputs (NPN or PNP), optional analog output
- Display: 3-digit LED (red/green)
- Accuracy: ±2% F.S.
- Response Time: ≤2.5 ms (adjustable)
- Operating Temp: 0–50°C
- Connection: R1/8 (male thread)
- Protection: IP40
Uses:
- Pneumatic and hydraulic pressure monitoring
- Industrial automation systems
- Robotics and pick-and-place units
- Packaging and filling machines
- HVAC and air compressor controls
- Safety and process control in factories
Benefits:
- Helps prevent overpressure conditions with precise monitoring
- Increases system efficiency through accurate pressure control
- Reduces downtime with real-time alerts and quick response
- Simple to configure and integrate into existing setups
- Compact size saves panel space
- Energy efficient with low power consumption
Package includes:
- 1x SMC ISE30-01-28 MPa Digital Pressure Switch (used)
