PT100 4-20mA Temperature Sensor Temperature Thermometer

1 total reviews

Regular price Rs 6,100
Regular price Rs 6,000 Sale price Rs 6,100
Sale Sold out
BR4948

PT100 4-20mA Temperature Sensor Temperature Thermometer temperature transmitter is approved by PROFIBUS Nutzerorganisation e.V. For temperature sensor we can provide the thermal resister, thermocouple, etc usually used in industry, we can also provide special sensor, including high-temperature type, high-pressure type, health type, with special material or with coating, etc sensor. A customized sensor is also acceptable.

Features:

  1.   High precision, digital precision up to ±0.01ºC
  2.   Long-term drift<0.1/year
  3.   Install easily, more flexible
  4.   To reduce the overall cost of installation, maintenance, and running.
  5.   4~20mA/Hart/Profibus PA output all available
  6.   Self-diagnostics function
  7.   LCD display, Menu-guided operation

Specifications:

  • Measuring media liquid, gas, and steam
  • Measuring range -270~800 ºC (PT100 thermal resistor)
  • 0~1300ºC, (Thermocouple K)
  • Input Thermocouple, RTD, MV, Resistive sensor
  • Power supply range 9~45V (9~24V, Ex)
  • Output signal 4~20mA/Hart/Profibus PA
  • Digital Accuracy ±0.01ºC, PT100 input
  • Internal cold end compensation error <0.25ºC±0.1%/10ºC
  • Temperature drift ±0.05%/10ºCfull scale range
  • 0.1% between-10°C to 60°C
  • Effect of power supply on the range <0.005%/V full-scale range
  • Long term drift <0.1/year
  • Ambient temperature Ambient temperature Storage temperature
  • T4 Safe operation(T6)
  • -40...85ºC -40...60ºC -40...95ºC
  • Protection Class IP66/67
  • Relative humidity ≤98%, condensation allowed
  • Electromagnetic compatibility Accordance with EN 61 326

Industryparts.pk is the Best Online Shopping website for PT100 4-20mA Temperature Sensor Temperature Thermometer. Here you get PT100 4-20mA Temperature Sensor Temperature Thermometer at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.

Package Includes:

1 x PT100 4-20mA Temperature Sensor Temperature Thermometer






Description

PT100 4-20mA Temperature Sensor Temperature Thermometer temperature transmitter is approved by PROFIBUS Nutzerorganisation e.V. For temperature sensor we can provide the thermal resister, thermocouple, etc usually used in industry, we can also provide special sensor, including high-temperature type, high-pressure type, health type, with special material or with coating, etc sensor. A customized sensor is also acceptable.

Features:

  1.   High precision, digital precision up to ±0.01ºC
  2.   Long-term drift<0.1/year
  3.   Install easily, more flexible
  4.   To reduce the overall cost of installation, maintenance, and running.
  5.   4~20mA/Hart/Profibus PA output all available
  6.   Self-diagnostics function
  7.   LCD display, Menu-guided operation

Specifications:

  • Measuring media liquid, gas, and steam
  • Measuring range -270~800 ºC (PT100 thermal resistor)
  • 0~1300ºC, (Thermocouple K)
  • Input Thermocouple, RTD, MV, Resistive sensor
  • Power supply range 9~45V (9~24V, Ex)
  • Output signal 4~20mA/Hart/Profibus PA
  • Digital Accuracy ±0.01ºC, PT100 input
  • Internal cold end compensation error <0.25ºC±0.1%/10ºC
  • Temperature drift ±0.05%/10ºCfull scale range
  • 0.1% between-10°C to 60°C
  • Effect of power supply on the range <0.005%/V full-scale range
  • Long term drift <0.1/year
  • Ambient temperature Ambient temperature Storage temperature
  • T4 Safe operation(T6)
  • -40...85ºC -40...60ºC -40...95ºC
  • Protection Class IP66/67
  • Relative humidity ≤98%, condensation allowed
  • Electromagnetic compatibility Accordance with EN 61 326

Industryparts.pk is the Best Online Shopping website for PT100 4-20mA Temperature Sensor Temperature Thermometer. Here you get PT100 4-20mA Temperature Sensor Temperature Thermometer at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.

Package Includes:

1 x PT100 4-20mA Temperature Sensor Temperature Thermometer
