The PFR‑12 Reactive Power Compensation Controller is a smart 12‑step power factor (APFC) relay that maintains target cosφ and reduces penalty charges in commercial and industrial panels across Pakistan. It continuously monitors PF, voltage, and current via a CT and then switches capacitor steps automatically to correct lagging or leading PF. Setup is straightforward: set CT ratio, target PF, switching mode, and delays using the front keys and clear display.
Optimized algorithms reduce hunting and contactor wear, while protections such as over/under‑voltage, step inhibit, and harmonic lockout (model dependent) enhance reliability. The PFR‑12 supports 230/400 VAC, 50/60 Hz systems and provides 12 relay outputs to drive capacitor contactors or thyristor modules. Status LEDs and alarms make diagnostics fast.
Features:
- 12‑step automatic power factor control
- Quick setup: CT ratio, target cosφ, delays
- Optimized switching reduces hunting and wear
- Protections: O/V, U/V, step inhibit; harmonic lockout (model dep.)
- Bright display, status LEDs; panel‑mount 96×96 mm
Specifications:
- System: 3‑phase, 230/400 VAC, 50/60 Hz
- CT Input: 5 A (programmable CT ratio, e.g., 5–5000 A)
- Steps/Outputs: 12 relay outputs (e.g., 5A @ 250 VAC, model dep.)
- Setpoint: target PF ~0.80–0.99 (lead/lag selectable)
- Mounting/Cutout: 96×96 mm; cutout ~92×92 mm; optional RS‑485 (model dep.)
Uses:
- APFC capacitor banks in LV panels
- Shopping malls, hospitals, office towers
- Manufacturing plants and workshops
- Cold storage, HVAC chillers, elevators
- Diesel/utility mains (consult for generators)
Package Includes:
1 x PFR-12 Reactive Power Compensation Controller
