JKN JVM-1 Phase Failure Voltage Monitor
SKU:BR5305
Couldn't load pickup availability
JKN JVM-1 Phase Failure Voltage Monitor in Pakistan BR5305
Features:
- Phase sequence failure and Lack of phase protection relays.
- Available 3 wire
- Power Supply:3 x 110V AC, 3 x 220V AC, 3 x 380V AC, 3 x 400V AC , 3 x 415V AC,50/60Hz.
- Contact output: 10 A at 250 VAC/30 VDC, resistive load.
- Socket mounted with a PF083A(E) Socket
- Contact version: SPCO output
- LED fault indication
Specifications:
| Product Type | JVM-1 |
| Dimensions (mm) | 61H × 49W × 70D |
| Mouniing & Socket | PF083A(E) |
| Functions | To prevent the reverse run of three-phase induction motor |
|
In addition, the power surge absorber to prevent high voltage, which can effectively protect the load |
|
| With phase sequence, phase lack protection function | |
| Life | Mechanical 5×106times |
| Electrical 1×105times | |
| Rated voltage | AC(V):220,240,380,415,440, 50/60Hz |
| Indicator operating | Normal Operating |
| Contact rating | 10A 250VAC(Resistive load) |
| Insulation resistance | 100MΩ(DC 500V)min |
| Dielectric strength | 1500VAC |
| Consumed power | 2VA |
| Ambient temperature | -10℃~+55℃ |
| Ambient humidity | 48~85%RH |
| Weight | 90g |
Best Online Shopping website for JKN JVM-1 Phase Failure Voltage Monitor. Here you get JKN JVM-1 Phase Failure Voltage Monitor at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
Package Includes:
1 x JKN JVM-1 Phase Failure Voltage Monitor
