FBs-1LC Fatek Plc module in pakistan BR1357

 Introduction    FBs-1LC is one of the analog input modules  of FATEK FBs series PLC. It supports one  channels of load cell input for weight  measurement. The raw conversion result is  represented by a signed 16 bit integer value.  In order to filter out the field noise imposed  on the signal, it also provides the average of  sample input function.

Specifications:

 Total Channels - 1  A/D Converter Utilized – 24-bit ?-? A/D  Resolution- 16 bits (include signed bit)  I/O Points Occupied - 1 RI(Input Register) and 8 DO  Conversion Rate- 1/3/5/8 Hz  Non-Linearity- 0.01% F.S. (@25?)  Zero Drift- 0.2 µV/?  Gain Drift- 10 ppm/?  Excitation Voltage – 5V with 100? driving capability  Sensitivity - 2mV/V, 5mV/V, 10mV/V, 20mV/V  Software Filter- Moving average  Average Samples- 1~8 configurable  Isolation- Transformer(Power) and photo-coupler(Signal)  Indicator(s) - 5V PWR LED  Supply Power- 24V-15%/+20%, 2VA  Internal Power Consumption- 5V, 100mA  Operating Temperature- 0 ~ 60 ?  Storage Temperature- 20 ~ 80 ?  Dimensions- 40(W)x90(H)x80(D) mm
