System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electro mechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200 to save 50% space.
Specification:
- Type of product: Miniature Circuit Breaker
- Number of Poles: 2
- Current Rating: 20A
- Tripping Characteristics: Type C
- Rated AC Voltage: 400V
- Breaking Capacity at Maximum Voltage Rating: 6 kA
- Range: System M Pro
- Length: 88mm
Industryparts.pk Best Online Shopping website for ABB Miniature Circuit Breaker S202-C20 2P 400V 20A in Pakistan. We deliver in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
Package includes:
1 x ABB Miniature Circuit Breaker S202-C20 2P 400V 20A
