300amp To 5Amp Current Transformer

1 total reviews

Regular price Rs 441
Regular price Rs 450 Sale price Rs 441
Sale Sold out
BR1809-B204

300amp To 5Amp Current Transformer in pakistan BR1809



Features:



  • AC Circuit, 300/5 Rated Current Ratio.
  •
  • The middle of the window for the bus to wear around.
  •
  • Protects equipment against circuit damage.
  •
  • Tests, controls, displays and records electrical equipment operation
  •


Specification:


Item NameCurrent Transformer
Model NumberBH-0.66CT
Rated Current Ratio300/5
Accuracy Class0.5
Rated Voltage0.66KV
Working Frequency50Hz - 60Hz
Conductor Through1T
Primary Current300A 10VA
Secondary Current5A 50/60Hz 660V
Opening Size32 x 25mm/1.2" x 1“(L*W)
Total Size6 x 3.6 x 8cm/2.4" x 1.4" x 3.1"(L * W * H)
Case MaterialPlastic
ColorGray
Package Content1 x Current Transformer    Several Mounting Accessories
 300amp To 5Amp Current Transformer in Pakistan  Fixing methods:1 side base; Busbar mounting  transparent terminal cover.  Primary current up to 300A.    Continuous overload (Id) 1.2In  Operating temperature -10°C ~ 50°C  Housing self-extinguishing class VO  Safety factor FS<5  Secondary current 5A, 1A

Description

300amp To 5Amp Current Transformer in pakistan BR1809



Features:



  • AC Circuit, 300/5 Rated Current Ratio.
  •
  • The middle of the window for the bus to wear around.
  •
  • Protects equipment against circuit damage.
  •
  • Tests, controls, displays and records electrical equipment operation
  •


Specification:


Item NameCurrent Transformer
Model NumberBH-0.66CT
Rated Current Ratio300/5
Accuracy Class0.5
Rated Voltage0.66KV
Working Frequency50Hz - 60Hz
Conductor Through1T
Primary Current300A 10VA
Secondary Current5A 50/60Hz 660V
Opening Size32 x 25mm/1.2" x 1“(L*W)
Total Size6 x 3.6 x 8cm/2.4" x 1.4" x 3.1"(L * W * H)
Case MaterialPlastic
ColorGray
Package Content1 x Current Transformer    Several Mounting Accessories
 300amp To 5Amp Current Transformer in Pakistan  Fixing methods:1 side base; Busbar mounting  transparent terminal cover.  Primary current up to 300A.    Continuous overload (Id) 1.2In  Operating temperature -10°C ~ 50°C  Housing self-extinguishing class VO  Safety factor FS<5  Secondary current 5A, 1A
