PIR Motion Sensor detects the presence and motion of any people, animals, or other objects. 220V Infrared Motion Detector adopts a high-sensitivity detector and integrates circuits and SMT. This PIR on-off switch can automatically identify day and night, and the external environment illuminance can freely choose the starting job. Indoor Motion Sensor is a new type of energy-saving lighting switch. An electric motion detector switch utilizes human motion infrared rays as control signal sources when one enters the detection field, it will start the controlled load at once.
Features:
- Easy to install.
- Automatic, convenient, safe, and practical.
- It has the function of power and detection indication.
- The motion sensor can identify day and night automatically.
- It has a wide detection range made up of up and down, left, and right service fields.
- This product is a new type of energy-saving lighting switch.
- It adopts a high-sensitivity detector and integrates circuits and SMT.
- It utilizes human motion infrared rays as control signal sources,
- when one enters the detection field, it will start the controlled load at once.
Specifications:
- Color: Black
- Material: ABS
- Working Rotation: 180 Degree
- Voltage: AC85V~265V, 110V-220V
- Standard: LVD, EMC, CE, RoHS
- IP Rating: Indoor application IP44
- LUX Setting: 2-2000lux svr adjustable
- Size: As shown in the picture
- Induction lighting time: 5s~6min adjustable time
- Detection distance: Approx 12M, installation 1.5-2.5M High
Connection:
- Blue color: Negative line (-)
- Brown shade: Live wire (+)
- Red: Ground wire
Note: For the 220v motion sensor, you just provide 220V voltage to the sensor, don't need the driver.
Package Include:
- 1x 220V Automatic Infrared PIR LED Motion Sensor Detector Switch
