2 Inch 220V AC Solenoid Valve Pakistan
Need a reliable large-size solenoid valve for air or water lines? This 2 inch 220V AC solenoid valve is built for high flow, clean switching, and low maintenance in Pakistani conditions. It fits DN50 pipelines with female BSP threads and runs on standard 220V AC 50/60 Hz power. The valve is normally closed, pilot‑operated for smooth opening, and uses a durable brass body with NBR/EPDM seal options for long service life.Use it on water supply, RO plants, irrigation, air compressor piping, chillers, and general industrial automation. Response is fast, sealing is tight, and the coil is IP65 protected against dust and light moisture. Typical working pressure is 0.5–7 bar with a small differential pressure required to open, making it ideal for gravity and pump systems alike. Installation is simple: follow the arrow for flow direction, keep the coil upright, and add a filter to protect from debris.
Features of 2 Inch 220V AC Solenoid Valve Pakistan:
- 2" DN50 high‑flow, Normally Closed (NC)
- 220V AC coil, IP65 moisture/dust protection
- Brass body with durable NBR/EPDM seals
- Pilot‑operated design for smooth, quiet switching
- Female BSP threads; easy inline installation
Specifications:
- Port Size: 2 inch (DN50) BSP/NPT female
- Voltage/Coil: 220V AC, 50/60 Hz, IP65
- Operation: Normally Closed (NC), pilot‑operated
- Working Pressure: approx. 0.5–7 bar (min ΔP required)
- Media Temp: up to ~80°C water; ~60°C air
Uses:
- Water supply and RO plant control
- Irrigation and tank level automation
- Air compressor and pneumatic lines
- HVAC chilled water loops
- Industrial washing/process equipment
- Water supply and RO plant control
- Irrigation and tank level automation
- Air compressor and pneumatic lines
- HVAC chilled water loops
- Industrial washing/process equipment
