LA39-B2 series has a clear visual arrangement. The high-strength PBT plastic parts are combined with the straight screws for fixation, which not only continues the stable and solid feature of A1 B1 C1 but also considers the manufacturing cost. It is the simplified type of A1 B1 C1 to provide multiple economic options to the users.
Features
- The Rated Insulation voltage is AC 600V (50Hz). The conventional thermal current is 10A.
- Mechanical Endurance: 3×10ˆ5 times.
- Electrical Endurance: 6×10ˆ5 times.
- Contacts resistance < 50mΩ.
Specifications:
- Selector switches type:2 position short lever selector switch
- Switching action:2 position return center from left
- Contacts:1NO
- Lever Color: Black
- Mounting diameter:22mm
- Front bezel material: Plastic
-
Front bezel shape: Circular
Best Online Shopping website for 22mm selector switches made in China Circular electrical rotary switches. Here you get 22mm selector switches made in China Circular electrical rotary switches at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
Package Includes
1 x Circular Electrical Rotary Switches
