An Ultrasonic 60W 40KHz Cleaning Transducer is a device that converts electrical energy into high-frequency sound waves (ultrasound) at 40,000 vibrations per second, with a power output of 60 watts. This ultrasound creates tiny bubbles in a cleaning liquid that violently collapse (a process called cavitation), effectively scrubbing dirt and contaminants off submerged objects without physical abrasion. It's a core component in ultrasonic cleaning machines for various industries.
Features of the Ultrasonic 60w 40KHz Vibration Cleaning Transducer:
- High-efficiency piezoelectric ceramics ensure strong ultrasonic vibrations.
- Durable 304 stainless steel construction offers heat and corrosion resistance.
- A homogeneous sounding board provides uniform energy distribution.
- Secure bolt-on mounting enhances mechanical stability.
- Some models offer adjustable power/frequency for fine-tuning.
Specification of the Ultrasonic 60w 40KHz Vibration Cleaning Transducer:
- Power: 60W
- Frequency: 40KHz (40,000 Hz)
- Material: 304 Stainless Steel (housing), Piezoelectric Ceramic (elements)
- Dimensions: Typically around 45-50mm diameter, 48-54mm height
- Resonant Impedance: 15-25$\Omega$ (Ohms)
- Capacitance: Around 3500-3900 pF (picofarads)
- Weight: Approximately 230-300g
- Operating Temperature: Typically
Uses:
- Ultrasonic cleaning machines (primary use).
- Precision cleaning for delicate items (jewelry, electronics, medical tools).
- Industrial cleaning (automotive, aerospace parts).
- Beauty & medical applications.
- Research & development.
Benefits:
- Thorough, non-abrasive cleaning reaches intricate areas.
- Versatile for various materials and contaminants.
- Increased efficiency by reducing labor and ensuring consistent results.
- Durable with a long lifespan and robust construction.
- Environmentally friendly by minimizing chemical use.
Package includes:
- 1x Ultrasonic 60w 40KHz Vibration Cleaning Transducer
