The OMRON EE-SX670 is a type of sensor, specifically a slot-type photomicro sensor, used to detect objects passing through a small gap. It operates using a through-beam method, meaning it has a light emitter and receiver, and an object breaking the beam is detected. This sensor is manufactured by Omron, has an NPN output, and can be set to either Dark-ON or Light-ON operation. It's designed for a DC power supply ranging from 5V to 24V, and it's commonly used in automation and control systems for tasks like object detection, position sensing, and counting.
Features of OMRON EE-SX670 Micro Photoelectric Sensor:
- Slot-type design: The sensor has a U-shaped structure with a slot.
- Through-beam sensing: Detects objects by sensing when they interrupt a light beam.
- Sensing distance: 5mm slot width.
- Light source: Infrared LED.
- Output type: NPN output.
- Operation mode: Selectable between Dark-ON and Light-ON.
- High response frequency: Up to 1 kHz.
- Compact size
- Easy operation monitoring: Bright light indicator.
- Wide operating voltage range: 5 to 24 VDC.
- Housing material: PBT (Polybutylene Terephthalate) case.
- Connector type: Connector.
Specifications of OMRON EE-SX670 Micro Photoelectric Sensor:
- Sensing method: Through-beam with slot
- Sensing distance: 5 mm
- Light source: Infrared LED
- Power supply: 5 to 24 VDC
- Output type: NPN
- Operation mode: Dark-ON/Light-ON selectable
- Response time: 0.17 ms
- Operating temperature: -25 to +55°C
- IP rating: IP50
Uses:
- Object detection: Detecting the presence or absence of objects.
- Position sensing: Determining the position of an object.
- Counting: Counting objects as they pass through the sensor's slot.
- Motion detection: Detecting movement.
- Edge detection: Detecting the edge of an object.
- Part inspection: Verifying the presence or correct positioning of parts.
- Automated assembly lines: Used in manufacturing for quality control and part handling.
- Packaging machinery: Monitoring material handling and product flow.
- Conveyor systems: Detecting objects on a conveyor belt.
- Robotics: Position and movement control
Benefits:
- Accurate detection: Provides reliable and accurate object detection.
- Fast response: High-speed response for quick detection of fast-moving objects.
- Versatile operation: Selectable Dark-ON/Light-ON operation for different application needs.
- Wide voltage range: Compatible with various power supplies.
- Compact design: Small size allows for installation in space-constrained areas.
- Durable construction: Robust housing for use in industrial environments.
- Easy installation:
- Non-contact sensing: Does not require physical contact with the object being detected.
- Long lifespan:
- Cost-effective
Package includes:
- 1x OMRON EE-SX670 Micro Photoelectric Sensor
Industryparts.pk is the Best Online Shopping website for OMRON E-SX670 Micro Photoelectric Sensor. Here you get OMRON E-SX670 Micro Photoelectric Sensor at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
