Automotive Relay Green Led Indicator Light JD2914 24V 80A 5pin BR6670
DESCRIPTION:
- Product Name: Automotive Relay
- Item No. : JD1912-12V/4P, JD2912-24V/4P, JD1914-12V/5P, JD2914 -24V/5P
- Applicable Range: Universal automobile
- Plug-in Leg No.: 4P, 5P
- Product Details:
Contact Form: 1A/1B/1C/1U/2A
Contact Material: Silver alloy
Rated Switching Current: 30A/40A/60A/80A
Contact Resistance: 50mQ
Coil Voyage: 12V/24 V DC
Coil Power Consumption: 1.8W
Between open Contacts: 550V AC
Between Coil and Contacts: 750V AC
Insulation Resistance: loom
Electrical Life Expectancy: 100000 times
Mechanical Life Expectancy: 100000000 times
Operating Temperature Range: -40°C+85°C
Operating Time: 10ms
Release Time: 5 ms
Structure Washable: according to customer requirements
Terminal Shape: Plug-in, PCB
External Dimension: 28x28x25.5mm
Shell Mode: Flat Shell, Metal Bracket, Plastic Bracket
SPECIFICATION:
- Brand Name: TIENEN
- Theory: Electromagnetic Relay
- Size: Subminiature
- Contact Load: Low Power
- Model Number: JD2914
- Usage: AUTO
- Protect Feature: Sealed
Package includes:
1 x Automotive Relay Green Led Indicator Light JD2914 24V 80A 5pin
