The Solid State Relay – SSR3-150DA allows you to control high current AC loads from lower voltage DC control circuitry. Solid-state relays have several advantages over mechanical relays. One such advantage is that they can be switched by a much lower voltage and at a much lower current than most mechanical relays, and since there are no moving contacts, solid-state relays can be switched much faster and for much longer periods without wearing out.
Features:
- Reliable SMT technology
- Reliable SMT technology
- High dielectric over 2.5KV
- Low EMI/EFI & surge by zero cross trigger method
- High surge current over 410A/one cycle (60Hz)
- High surge voltage duration by the snubber circuit
Specification:
- Model: SSR3-150DA
- Control Mode: DC-AC
- Load Voltage: 24-450VAC
- Load Current: 40A
- Control Voltage: 3-32VDC
- Control Current: DC3-25mA
- Working voltage: 150V
- On voltage: ?1V
- One-off Time: ?10ms
- Off leakage Current: ?2mA
- Installation Method: Bolt Fixed
- Working Indication: LED
Industryparts.pk Best Online Shopping website for Solid State Relay SSR 3, 3 Phase Module (Tense). Here you get Solid State Relay SSR 3, 3 Phase Module (Tense) at a reasonable price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Quetta, Multan, and all over Pakistan.
Package Includes:
1 x Solid State Relay SSR 3, 3 Phase Module (Tense)
