Inductive Proximity Sensor Switch – LJ18A3-8-Z/BY in Pakistan BR2582
Inductive Proximity Sensor Switch – LJ18A3-8-Z/BY
This Inductive Proximity Sensor Switch – LJ18A3-8-Z/BX is a component widely used in the automatic control industry for detecting, controlling, and non-contact switching. It’s widely used in the machine, paper making, light industry for limiting station, orientation taking count, speeding trial, etc.
Specifications:
Product Name | Inductive Proximity Switch |
Model | LJ18A3-8-Z/BY |
Wire Type | DC 3 Wire Type (Black, Brown, Blue) |
Switch Appearance Type | Cylinder Type |
Theory | Inductive Sensor |
Output Type | PNP NO (Normally Open) |
Diameter of Head | 18mm |
Detecting Distance | 8mm |
Supply Voltage | DC 6-36V |
Current Output | 300mA |
Detect Object | Iron |
Operating Temperature | -25°C to +55°C (Non-freezing Condition) |
Size | 7 x 3cm/2.8” x 1.2” (L*Max. Dia) |
Cable Length | 103cm / 40.55? |
External Material | Plastic, Alloy |
Net Weight | 77g |
Package Content | 1 x Inductive Proximity Switch |
