E2E-X18ME1-M1, E2E Series 18 mm Sensing Distance Proximity Sensor with M12 4-Pin Connector in Pakistan BR2776
Specification:
| Type | Proximity Sensor |
| Output Type | 3-Wire Direct Current (DC), Negative-Positive-Negative (NPN) |
| Sensor Type | Inductive |
| Range | 0 to 18 mm |
| DC Voltage | 12 to 24 V |
| Special Function | High-Quality Short Barrel Threaded Cylindrical Prox Conforms to Standard CENELC Sensing Distance. |
| Size | M30 |
| Shield Type | Unshielded |
| Contact Configuration | Normally Open (NO) |
| Case Material | Nickel-Plated Brass |
| Threaded Length | 30 mm |
| Overall Length | 58 mm |
| Mounting | Bracket with 30 mm Mounting Hole or M30x1.5 Threaded Hole |
| Mounting Hole Size | 30 mm |
| Industry Standards | CENELC |
| Electrical Connection | M12 4-Pin Connector |
| Sensing Distance | 18mm |
