4mm Sn Inductive sensor NBN4-12GM50-E2-V1 BR2266
Features:
- Switching function Normally open (NO)
- Output type PNP
- Rated operating distance 4 mm
- Installation non-flush
- Output polarity DC
- Assured operating distance 0 ... 3.24 mm
- Hysteresis type. 5%
- Nominal ratings
- Operating voltage 10 ... 30 V
- Switching frequency 0 ... 1200 Hz
- Reverse polarity protection Reverse polarity protected
- Short-circuit protection pulsing
- Voltage drop? 3 V
- Repeat accuracy ? 0.01 mm
- Operating current 0 ... 200 mA
- Off-state current 0 ... 0.5 mA typ. 0.1 µA at 25 °C
- No-load supply current? 17 mA
- Switching state indicator Multihole-LED, yellow
- Functional safety-related parameters
- MTTFd 990 a
Mechanical specifications:
- Connection type Connector M12 x 1 , 4-pin
- Housing material brass, nickel-plated
- Sensing face PBT
- Housing diameter 12 mm
- Degree of protection IP67
Specification:
- Brand Name:
- DIY Supplies: Electrical
- Model: NBN4-12Gm50-E0/E2-V1
- Types of electronic and electrical produ: Proximity switch/sensor
- Colour: Other /other
